This article is the first of many on distance signage. The metric conversion of distance signs can be spread over a longer period without any safety issues. In this article, we look at the conversions required for junction approach signs (for example on motorways) and services signs in particular. Currently these two types of signs are the most common signs where "m" has been incorrectly used to denote mile, this needs to be corrected. It is worth re-iterating that "m" is the international symbol for metre only.
It might be worth considering covering up the "m", or replacing "m" with "mi" or "mile"/"miles", where "m" has been incorrectly been used to abbreviate miles as pre-metrication preparatory work to eliminate confusion, especially on Services signs. It will not be a major safety issue if this preparatory work is not done.
Motorway junction ahead and similar signs
Metres should be used instead of kilometres on motorway junction ahead signs (and the equivalent signs for primary route and non-primary/local route signs) because there is greater flexibility (one is not just limited to 2 km or 1 km), one can avoid fractions, and be more accurate at the same time (e.g. 1600 m instead of 1.6 km or even 2 km). People are also familiar with large numbers of metres from athletics races. All signs need to have have at least 90% accuracy.The conversions from miles to kilometres could and should be as shown below:
| Before | After | Accuracy |
|---|---|---|
| 1⁄4 mile | 400 m | 99% |
| 1⁄3 mile | 500 m | 93% |
| 1⁄2 mile | 750 m | 93% |
| 1⁄2 mile | 800 m | 99% |
| 2⁄3 mile | 1000 m | 93% |
| 3⁄4 mile | 1200 m | 99% |
| 1 mile | 1500 m | 93% |
| 1 mile | 1600 m | 99% |
| 1 1⁄4 miles | 2000 m | 99% |
| 1 1⁄3 miles | 2000 m | 93% |
| 1 1⁄2 miles | 2400 m | 99% |
| 1 1⁄2 miles | 2500 m | 97% |
| 1 2⁄3 miles | 2500 m | 93% |
| 1 3⁄4 miles | 2800 m | 99% |
| 1 3⁄4 miles | 3000 m | 93% |
| 2 miles | 3000 m | 93% |
| 2 miles | 3200 m | 99% |
Note that there are some choices, for example to convert 1 mile it could be converted to either 1500 m or 1600 m. Similarly ½ mile can be converted to either 750 m or 800 m. As signs are placed at either 500 m or 800 m intervals typically, the most common signs would end up being 1600 m followed by 800 m, or 1000 m followed by 500 m, or 1500 m then 1000 m then 500 m, and you may occasionally see 1200 m and 400 m signs too. For 2 miles I strongly recommend converting to 3000 m instead of 3200 m where possible, on the rare occasions that 2 miles appears on the signs. As an alternative to having 1600 m then 800 m signs one can have 1500 m then 750 m signs, but one needs to be consistent.
Either way, only metres should be authorised on motorway (and dual carriageway and other similar exit signs), and on no account should kilometres or any other unit be allowed. Common sense would dictate that 1500 m means 1500 metres, not 1500 miles.
Example converted junction approach signs are shown below. On the top row are examples for motorways, the middle row shows primary routes, and the bottom row has an example sign for a non-primary/local route:
An example motorway overhead gantry sign is shown below:
More example motorway signs as well as suggested improvements will appear in a future article.
All motorway signs which need conversion can have the relevant imperial measurements plated with the metric equivalents, and there is no need to replace the whole sign unless the sign already needs to be replaced due to wear.
Services signs
All services signs have perhaps the most common and obvious incorrect usage of "m" to mean miles. This also needs to be corrected. This applies for both Services signs and services junction ahead signs.An example converted Services sign is shown below:
Having said that, there is one type of services sign that will always need to be in metres, the Services junction ahead sign. Examples of such signs are shown below:
